CNC dual head round and straight tenoning machine. Using its two opposing heads, balestrini fox can cut two identical or different tenons at the same time. All adjustments and machining are controlled by CNC. Thanks to programmable toolpaths and its fast loader, this tenoning machine can offer unparalleled productivity.
Balestrini Fox Dual CNC
CNC dual head round and straight tenoning machine. Using its two opposing heads, balestrini fox can cut two identical or different tenons at the same time. All adjustments and machining are controlled by CNC. Thanks to programmable toolpaths and its fast loader, this tenoning machine can offer unparalleled productivity.
In Stock
Technical data
| fox t | fox plus | fox lynx | |
| WORKPIECE SECTION (WIDTH X THICKNESS) | max. 160×60 (manual loading)/ 120×60 (automatic loading) – min. 10×10 / 15×8 mm |
max. 60×60 / 160×60 (manual loading)/ 120×60 (automatic loading) – min. 10×10 / 15×8 mm |
max. 75×25 mm – min 38×20 mm |
| WORKPIECE LENGTH | max. 2000 mm (2500 upon request) – with straight cut – min 175 mm | max. 2000 mm (2500 upon request) – with straight cut – min 175 mm | cross-section 75×25 mm (estimated on long side): max 1950 mm – min 178 mm cross-section 38×20 mm (estimated on long side): max 1870 mm – min 102 mm cross-section 38×20 mm (estimated on short side): min 25 mm |
| MORTISING OR DRILLING MAX. DEPTH | – | It depends on tool length 50 mm | – |
| MORTISE/HOLE DIMENSIONS IT STRICTLY DEPENDS ON INSTALLED TYPE TOOL | – | hole diameter: 1 ÷ 16 mm mortise thickness: 1 ÷ 30 mm |
mortise width: 1÷30 mm mortise length hor. max. 80 mm + width mortise depth: 1÷30 mm |
| TENONS DIMENSIONS IT STRICTLY DEPENDS ON INSTALLED TYPE TOOL | dowel diameter: 0÷30 mm tenon thickness: 0÷30 mm max length vert. tenon: 80 mm tenon depth: 6÷50 mm inclination: 0÷90° |
dowel diameter: 0÷30 mm tenon thickness: 0÷30 mm max length vert. tenon: 80 mm tenon depth: 6÷50 mm inclination: 0÷90° |
tenon thickness: 1÷30 mm tenon length hor. max. 80 mm + thickness tenon depth: 1÷30 mm |
| CUTTING ANGLES | heads rotation: -22,5° ÷ +45° heads inclination: -20° ÷ +45° |
heads rotation: -22,5° ÷ +45° heads inclination: -20° ÷ +45° |
– |
| MAX. HOURLY PRODUCTION | with RBF2 loader: 2400 tenons/h. | with RBF2 loader: 2400 tenons/h. | with RBF2 loader: 400 tenons/h. |
| TENONING CYCLE TIME | 1’’ approx | 1’’ approx | – |
| DRILLING AND CUTTING CYCLE TIME | – | Due to holes number | – |
| MINIMUM CYCLE TIME WITH SIMULTANEOUS MOVEMENT OF THE HEADS MOVEMENT OF THE TWO HEADS | – | – | Long pieces and small section with hopper feeder: 9” Short pieces and small section with hopper feeder: 12,5” |
| LOAD/UNLOAD CYCLE TIME | with RBF2 loader: 2” approx | with RBF2 loader: 2” approx | with RBF2 loader: 2″ approx |
