Suction Compact internal dust extractor – version with hopper and rotary valve FC250-FC320-FC380-FC450

Reliable, silent, and easy to install and to use. The F compact range has been designed with the aim of optimizing the extraction efficiency reducing at minimum the unit sizes. F SERIES is suitable for the extraction of chips and dust of various natures, optimal for the filtration of medium-fine particles.
They can be installed inside the workshop (please check the local rules) or even outside.
These filters are conceived to work in negative pressure, and they allow to reach depression values higher than other filtering units on the market while keeping maximum silence.
The unit is made up of galvanized painted panels and it is equipped with:
– air settling chamber at the inlet, to protect the filters from the impact with the transported materials.
– non-return valve (not certified), to avoid any pressure return to the workshop.
– high-density polyester filtering sleeves (500 gr / m) or cartridges (270 gr / m2) upon model.
– filters cleaning system by countercurrent compressed air jet pulses, blown during the extraction running.
– soundproof high-efficiency centrifugal backward curved fan, installed internally on the clean air side.
– hopper with rotary valve for a continuous waste discharge (on a pneumatical transfer system, diagonal screwconveyor, by gravity into a bin/big-bag/skip, etc.).

ATEX version includes:
– ATEX II 3D certified fan;
– ATEX anti-static polyester filtering sleeves (or cartridges);
– an anti-explosion panel with break-detection probe.

PLEASE NOTE: in case of hydrophile dust we recommend the hopper with screw conveyor.
